Noryl Plastic Sheet & Rod

Noryl provided by Interstate Plastics is a strong thermoplastic with outstanding strength, stiffness, mechanical, thermal, and electrical properties.

What is Noryl Plastic?

Noryl plastic is a strong machinable thermoplastic with outstanding strength, stiffness, mechanical, thermal, and electrical properties. Low moisture absorption and low thermal expansion make Noryl one of the most dimensionally stable thermoplastics available.

It is widely used for electrical housings and structural components since it has excellent insulating properties, flame resistance, and dimensional stability over a wide range of service temperatures, and is often selected for fluid handling applications since it has low moisture absorption and excellent strength and stiffness.

Noryl is easily machined, fabricated, painted and glued.

Excellent dimensional stability
Low moisture absorption
Wide range of service temperatures
Continuous use up to 220°F
Good impact resistance
High dielectric strength
Easy to fabricate, paint, and glue
Lightweight
Excellent flammability rating

Noryl Applications

Common applications include:

Manifolds
Pump, valve, and fitting applications
Brackets
Structural components
Internal appliance components
Scientific and analytical instrument components
Electrical housings
Covers
Electrical components

Physical Properties of Noryl

Density

0.0383 lbs/in.³

Tensile Strength @ Break

9200 psi

Tensile Modulus

350 ksi

Elongation @ Break

25%

Flexural Strength

13400 psi

Flexural Modulus

370 ksi

Izod Impact Strength, Notched

R119

Heat Deflection Temp.
66 psi / 264 psi

279°F / 254°F

Water Absorption @ 24H

0.07%

*Values listed are typical and are meant only as a guide to aid in design. Field testing should be performed to find the actual values for your application.

Prop 65 Warning WARNING: This product can expose you to chemicals including Carbon Black, CAS 1333-86-5, which are known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov.

Prop 65 Warning WARNING: This product can expose you to chemicals including Toluene, CAS 108-88-3, which are known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.

Product Title

Product Description

Noryl Sheet - Black EN 265

Noryl is strong with outstanding strength, stiffness, mechanical, thermal, and electrical properties.
