PEEK Plastic Sheet, Rod & Tube

PEEK plastic is a temperature-resistant engineered machinable thermoplastic with excellent chemical resistance, fatigue resistance and thermal stability.

PEEK exhibits superior mechanical and electrical properties with a maximum continuous working temperature of 480°F to 500°F and excellent retention of mechanical properties up to 570°F in a steam or high-pressure water environment.

Superior chemical resistance has allowed PEEK to work effectively as a metal/stainless steel replacement in harsh environments, and has proven to be a reliable replacement for other materials that cost up to 10 times more.

PEEK is inert to all common solvents and resists a wide range of organic and inorganic liquids. This is a versatile high performance plastic.

---

• Extreme chemical resistance, good mechanical properties
• Highly resistant to thermal degradation
• Excellent strength, stiffness and dimensional stability
• Lightweight compared to steel, aluminum and titanium
• Low coefficient of friction
• High wear resistance without lubrication
• Low toxicity when exposed to flames
• Glass filled grades are available
• Outstanding wear resistance

Property	Unfilled	30% Glass
Density (lb/in3)	0.047	0.056
Tensile Strength	16000 psi	15000 psi
Tensile Modulus	500 ksi	900 ksi
Flexural Strength	25000 psi	28000 psi
Flexural Modulus	600 ksi	1000 ksi
Elongation at Break	20%	3%
Water Absorption @24H	0.1-0.5%	0.1%
Izod Impact, Notched (ft-lb/in.)	1.0	1.4 - 1.84
Heat Deflection Temp.	306-320°F	599°F
Maximum Continuous Service Temp.	500°F	482°F
Melting Temp	644°F	644°F
Dynamic Coefficient of Friction	0.25	0.30

*Values listed are typical and are meant only as a guide to aid in design. Field testing should be performed to find the actual values for your application.
